Digital lectern Zurich
- Fast production to order
- 4,000+ satisfied customers
- Honest advice from our experts
- Post-payment possible
Smart podium with 22" full HD touch screen panel on the top and with he possibility to integrate a tablet controller system. With this system you will be able to control all features of the auditorium through the tablet: the sound system, microphone, switch on/off the projector, up/down the projector curtain, on/off the light or any other electrical devices in the room etc. Sliding top panel protects your touch display. Connector panels give ability to access to power, external projector, display devices, and audio systems. Below the highligts of the smart visual lectern:
- 22” Speaker screen, full HD, multitouch capacitive touch screen (Screen annotation and recording software included for the touch screen)
- High performance PC intel i3 4GB Ram, 120 GB SSD, Win 10 Embedded ioT
- Digital 3,5” touch screen clock, timer, stopwatch, chronometers on the top
- USB 3.0 port on the top surface
- Professional gooseneck condenser microphone
- Swithc Atlona SC-500 3x1 switcher with two HDMI inputs and one VGA input
- HD video scaler with HDMI output and input resolution control
- Optional tablet controller
Contact us to receive information about the shipping process and shipping costs.
Intelligent audivisual lectern Zurich
Smart podium with 22" full HD touch screen panel on the top and with he possibility to integrate a tablet controller system. With this system you will be able to control all features of the auditorium through the tablet: the sound system, microphone, switch on/off the projector, up/down the projector curtain, on/off the light or any other electrical devices in the room etc.
Highlights of smart visual lectern, Zurich
- 22” Speaker screen, full HD, multitouch capacitive touch screen (Screen annotation and recording software included for the touch screen)
- High performance PC intel i3 4GB Ram, 120 GB SSD, Win 10 Embedded ioT
- Digital 3,5” touch screen clock, timer, stopwatch, chronometers on the top
- USB 3.0 port on the top surface
- Professional gooseneck condenser microphone
- Swithc Atlona SC-500 3x1 switcher with two HDMI inputs and one VGA input
- HD video scaler with HDMI output and input resolution control
- Optional tablet controller
Technical specifications Computer lectern, Zurich
| Lecturer Panel | 22" |
| Screen Specifications | |
| Resolution | 1920x1080 FHD |
| Brightness | 250 cd/m2 |
| Panel Type | IPS |
| Aspect ratio | 16:9 |
| Touch Technology | Capacitive |
| Touch Points | 10 points |
| Lecturer Panel PC Specifications | |
| CPU | 4th Generation Intel Core i3 |
| RAM | 4 GB DDR4 |
| HDD | 120 GB SSD |
| Operating System | Windows Embedded 10 IoT |
| Microphone | |
| Length | 18" |
| No of microphone | 1 pc |
| Output Connector | 3-way XLR (Male) |
| Microphone Type | Cardioid |
| Frequency Response | 50 -18 kHz |
| Sensitivity (at 1,000Hz) | -60dB ± 3dB |
| Impedance | 220Ω |
| Power ON indicator | LED |
| Power requirement | 2 x Phantom Power (48V) |
| Inputs | |
| VGA | Available (On desk for Laptop) |
| Sound | 3,5mm jak (On desk for Laptop) |
| HDMI | Available (On desk for Laptop) |
| Ethernet | Available (On desk for Laptop) |
| 230V Plug (Max 5A) | Available (On desk for Laptop / mobile phone charge) |
| USB | USB 2.0 x 4 (On desk for internal PC) |
| Outputs (Bottom of Podium) | |
| VGA | Available |
| HDMI | Available (Projector Out) (max output 1080p) |
| RS232 | For Projector On/Off |
| Data Connection (Bottom of Podium) | |
| Ethernet 1 | Network Connection for Complete System |
